POLARIS Smart HMI 17,3"W / 21,5"W / 24"W
Benefits
- TPM 2.0 security standard,
Windows 11 compliant - Capacitive touch display
- Low reflection due to „optical bonding“
- Display resolution of 1920 x 1080 pixels
- Windows Operating System for external visualisation software
- front panel mounting for easy installation and integration
Marking
ATEX:
Ex II 3G Ex ec ic [ic IIC Gc] IIC T4 Gc
Ex II 3D Ex ec tc [ic IIC Gc] IIIC T120 °C Dc
Ambient Temperature
Operation: 0 °C up to +50 °CStorage: -20 °C up to +50 °C
Product Video
Description
The POLARIS Smart HMIs are an innovative, explosion-proof panel PC series. The devices are equipped with an Intel® processor N 97 or Intel® Core™ i5-1135G7 as standard. Windows 10 LTSC is used as the operating system. As a Thin Client solution, the BARTEC Zero Client Shell or PXE boot is available.
The POLARIS Smart HMI’s 17", 21.5", and 24" are available with a standard resolution of 1920 x 1080 pixels in 16:9 format and are designed for use in Zones 2 and 22. The devices come equipped with a multitouch display as standard, which uses optical bonding to ensure optimal contrast even in poor lighting conditions. Features include two Ethernet interface as well as various USB ports that can be used to connect different operating accessories such as keyboard, trackball and more.
Technical Data
| Structure |
Front-panel fitting |
|---|---|
| Display | 16,7 million colours HD (1920 x 1080 pixels) |
| Interface | Base version : 2 x Ethernet 2.5 Gigabit (internal RJ45) 2 x USB 3.2 Gen 1 (intern plug Type A) 2 x USB Exi Terminal (Keyboard & Mouse) 1 x USB Exi Type A (Data stick extern) Optional: Serial Interface RS232/422/485 |
| Operating system | Windows 10 IoT Enterprise 2021 LTSC (64 Bit) Windows 10 IoT Enterprise 2021 LTSC (64 Bit) and Zero Client APP Panel PC Windows 11 IoT Enterprise LTSC 2024 64 Bit |
*Refer to the documentation for more detailed information
