Product BARTEC SP9EX1 Smartphone

BARTEC SP9EX1 Smartphone

World's most compact 5G Smartphone for Zone 1/Division 1
17-S19P-31110110

Benefits

  • Compact and lightweight: Designed and optimized for all-day productivity and one hand use.
  • Intrinsically safe design: Over 1,000 dedicated components ensuring ex protection.
  • Fast 5G network connectivity: Qualcomm® QCM6490 processor supporting both public and private 5G network connectivity.
  • Low-light optimized camera: 48MP main camera and 8MP front camera for video calls.
  • Rugged: MIL-STD-810H and IP68 rated for water and dust resistance.

Get a Quote

Marking

ATEX:
Ex II 1G Ex ia IIC T4 Ga
Ex II 2D Ex ia IIIC T135°C Db IP 64

IECEx:
Ex ia IIC T4 Ga
Ex ia IIIC T135°C Db IP 64

NEC/CEC 500/505 (pending):
Class I, Div 1, Groups A, B, C and D
Class II, Div 1, Groups E, F and G
Class III, T4
Zone 0, AEx ia IIC T4 Ga
Zone 21, Aex ia IIIC T135° Db
Ex ia IIC T4 Ga
Ex ia IIIC T135° Db

Ambient Temperature

Operating Temperature
-20°C to +50°C (-4 °F to +122 °F)

Charging Temperature
0°C to +40°C (+32°F to +113°F)

Certification

Product Video

Description

Engineered for the utmost safety and performance in hazardous environments, the BARTEC SP9EX1 Smartphone is synonymous with reliability. Combining a robust yet refined design, it balances ruggedness with elegance, ensuring functionality without compromise. As the world’s most compact 5G smartphone for ATEX/IECEx Zone 1/21 and NEC Class I, II, III, Division 1 (pending), it sets a new standard in hazardous area communication.

With a broad range of accessories, Android 13TM, and comprehensive lifecycle support, the BARTEC SP9EX1 Smartphone ensures reliable performance from deployment throughout its lifespan, delivering exceptional safety and efficiency in even the most challenging environments.

Technical Data

Hardware Specifications

  • Processor: Qualcomm® QCM6490 Octa Core 2.7 GHz
  • Memory (RAM): 8 GB
  • Mass Storage: 128 GB
  • Display: 6.1" AMOLED
  • Resolution: 1080 x 2340 pixels
  • Front Glass: Gorilla® Glass Victus® (generation 8)
  • Touch Function: Capacitive Touch (Stylus, bare or gloved fingertip input)
  • Size (L x W x H): 168.7 mm x 83.4 mm x 17.9 mm (6.6 inch x 3.3 inch x 0.7 inch)
  • Weight (with battery): 350 g (0.77 lb)
  • Battery: Lithium-ion battery 3.68 V/4300 mAh (15.8 Wh)

Connectivity and Network

  • SIM: Dual SIM (Nano SIM + eSIM)
  • Wireless Connections: WiFi 6, 5G
  • Radio Frequency Band:
    • 5G NR (Bands: 1-3, 5, 7, 8, 20, 25, 28, 38, 40, 41, 48, 66, 71, 77, 78)
    • LTE (Bands: 1-5, 7, 8, 12, 13, 17, 20, 28, 38, 40, 41, 48, 66, 71)
    • UMTS (Bands: 1, 2, 4, 5, 8)
    • GSM (Bands: 850, 900, 1800, 1900)
  • WLAN-WiFi: Wi-Fi 6 IEEE 802.11a/b/g/n/ac/ax, 2x2 MU-MIMO, Dual band Simultaneous (up to 2042 Mbps data rate and 160 MHz bandwidth)
  • Bluetooth: Bluetooth® 5.2 (including Low Energy long range and multiple broadcasts)
  • GNSS: GPS, A-GPS, Glonass, Galileo, and BeiDou
  • NFC: Read/write NFC tags (e.g., ISO 14443 Type A), contactless payments, and card emulation

Camera and Audio

  • Back Camera: 48 MP with Auto Focus
  • Front Camera: 8 MP
  • Voice & Audio: Two microphones, Vibrate alert, Speaker, Bluetooth wireless headset support, High-quality speakerphone
  • Notifications: Audible tone, multi-color LEDs, vibration

Additional Features and Accessories

  • Operating System: Android 13TM
  • Operating Temperature: -20 °C to +50 °C (-4 °F to +122 °F)
  • Protection Class (IEC 60529): IP68
  • External I/O: Charging pins, USB-C Port
  • Sensors: Accelerometer/Gyroscope, Magnetometer/Compass, Pressure/Barometer, Proximity, Ambient light
  • Buttons: 1x on/off button, 2x programmable function button (for PTT, Emergency call or other functions), 1x volume buttons (+/-)
  • Scope of Delivery: BARTEC SP9EX1 Smartphone, Battery, Battery tool, USB-C cable, Quick Start Guide
  • Required (not included): USB-C Charger (e.g., Wall Charger Type G7-S0Z0-0014/0015/0016/0017)

Google is a trademark of Google LLC.
Qualcomm is a registered trademark of Qualcomm Incorporated

Battery documents

  • Battery - Material safety data sheets (MSDS)

  • Battery - Test summery for UN38.3

Manuals/Operating Instructions/Guides

  • BARTEC SP9EX1 Smartphone - Quick Start Guide

Declarations

  • BARTEC SP9EX1 Smartphone - EU-Declaration of Conformity

Data Sheets

Camera

Capture every detail with a 48MP main camera, also in low-light. 8 Megapixel front camera for video calls.

Audio

Cut through the noise anywhere with powerful dual loudspeakers.

5G

Stay ahead with faster data transfer, seamless communication, and enhanced productivity.

IP68 and MIL-STD-810H

Water and dust resistant, so you can confidently use it wherever you want.

Gorilla® Glass Victus®

More screen, less bezels with a bright 6.11” AMOLED display protected by Gorilla® Glass Victus®.

Powerful Performance

8 GB of RAM and 128 GB of integrated storage.
